Production
| Year | Model | Production Span | Units Assembled |
|---|---|---|---|
| 1929 | 52 | 06/1928 – 10/1929 (16 months) | 25,460 |
Note: Model 51’s were still in production until 10/1928
Car and Engine Serial Numbers
On early models (up to serial number 5,001,494 on Detroit cars), the serial number was placed on the instrument panel. After that, it was put on a plate that was attached to the left frame rail under the front fender. The body number and body code were put on a plate that was attached to the corner (left side of the engine) on the firewall. The engine number of the Model 50, 51, and 52 was stamped on an aluminum plate attached to the left rear side of the engine. On the Model 53, the engine number was stamped on a boss located on the right side of the engine just above the water jacket cover plate.
|
Year |
Model |
Serial Number Detroit |
Serial Number CA |
Engine Serial Number |
|---|---|---|---|---|
|
1929 |
52 |
5,047,001 to 5,073,000 |
5,950,251 to 5,951,410 |
F9-100,001 to 139,900
(This number is for both 1928 and 1929) |
1929 Erskine Specifications
Year | 1929 |
|---|---|
Model | 52 |
Bore | 2 3/4 |
| Stroke | 4 1/2 |
| Cubic Inches | 160.4 |
Horse Power | 43 |
Wheel Base | 109 |
Tire Size | 4.75 x 20 |
1929 Model 52 Body Styles
| Body | Passenger | Body Code | Wheels | Price | Weight |
|---|---|---|---|---|---|
Club Sedan (2dr) | 5 | F | Wood | $860 | 2,535 |
Sedan (4dr) | 5 | W | Wood | $945 | 2,600 |
Royal Sedan (4dr)* | 5 | W | Wire (6) | $1,045 | 2,745 |
Cabriolet | 2 | E | Wood | $875 | 2,420 |
Royal Cabriolet w/rumble seat* | 4 | E | Wire (6) | $995 | 2,605 |
Screen Delivery | 2 | B | Wood | ? | ? |
Panel Delivery | 2 | B | Wood | ? | ? |
*Six wire wheels were standard on Royal models. Other models could be ordered with five wire wheels for an extra $35.
